The Solar Photovoltaic Thermal (PVT) system generates both electricity and thermal energy in a single system resulting in significant rooftop space savings and can be used for various domestic and industrial applications.
- A Hybrid PVT system is a combination of Solar PV and Solar thermal system
- Generates hot water and electricity from a single system
- High energy density compared to individual solar PV and solar thermal system
- Potentially aims at utilizing the roof top space more effectively with area savings of 50%
Specifications:
| Parameters | Single Glaze | Double Glaze |
|---|---|---|
| Area | 8 m2 | 8 m2 |
| Solar Panel Rating | 1 kWe | 1 kWe |
| Maximum Outlet Water Temp. | 55°C | 65°C |
| System Output | 240-300 LPD | 480-600 LPD |
| Maximum ΔT | 30°C | 40°C |
| Peak Thermal Power | 0.8-0.9 k W | 2.4-2.7 k W |
| Average Thermal Efficiency | 10-13 % | 30-35 % |
| Average Electrical Efficiency | ~17 % | ~15 % |
Single Glaze
Double Glaze
